  • Dayton Audio RS225-8 8" Reference Woofer

Dayton Audio RS225-8 8" Reference Woofer

Read 54 Reviews | 182 Questions, 435 Answers or
Dayton Audio
Part #295-356

Dayton Audio RS225-8 8" Reference Woofer

Dayton Audio
Part #295-356
Model: RS225-8
Read 54 Reviews | 182 Questions, 435 Answers or
Alum Cone 4 OhmAlum Cone 8 OhmPaper Cone 4 OhmPaper Cone 8 Ohm
Dayton Audio Reference Series RS225-8 8" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.
Key Features
  • One of the lowest distortion, highest resolution driver series available
  • Low-distortion high-excursion motor system with two short-circuit paths
  • Compliant suspension and rigid black anodized aluminum cone for strong bass performance
  • Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
  • Designed and engineered in the USA
Similar items that may interest you:
  • Dayton Audio DSA215-8 8" Designer Series Aluminum Cone Woofer
    Price:$64.98       Part #295-530
  • Dayton Audio DA215-8 8" Aluminum Cone Woofer
    Price:$49.98       Part #295-332
See all items in Woofers
Your Price: $79.98
MSRP: $97.99
Save $18.01 (18%)
Bulk Pricing
Quantity:Qty: 1-3 $79.98/ea
Quantity:Qty: 4+$76.39/ea
Order in the next 0 hr 6 min to ship today. Details

In Stock

Get Notified When Available

We'll send you an email when Dayton Audio RS225-8 8" Reference Woofer is back in stock or available for preorder.
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy
Share
Share

Frequently Bought Together

Frequently Bought Together

$79.98
$189.98
$15.98
$5.98

Total Price: $291.92

This Product:Dayton Audio RS225-8 8" Reference Woofer$79.98
Dayton Audio RSS265HO-4 10" Reference Series HO Subwoofer 4 Ohm$189.98
Acousta-Stuf Polyfill 1 lb. Bag Speaker Cabinet Sound Damping Material$15.98
Parts Express Gold Recessed Binding Post Banana Jack 5-Way Speaker Terminal$5.98
4 ItemsTotal Price: $291.92

Overview

Dayton Audio RS225-8 8" Reference Woofer

The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS225-8 8" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

Product Details

BrandDayton Audio
ModelRS225-8
Part Number295-356
UPC844632088766
Unit of MeasureEach
Weight6.1

Product Specifications

Nominal Diameter8"
Bolt Circle Diameter8.23
Power Handling (RMS)80 Watts
Power Handling (MAX)160 Watts
Impedance8Ω
Frequency Response28 to 2,400Hz
Sensitivity86.8dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)28.3Hz
DC Resistance (Re)6.5Ω
Voice Coil Inductance (Le)0.86mH
Mechanical Q (Qms)1.46
Electromagnetic Q (Qes)0.51
Total Q (Qts)0.38
Compliance Equivalent Volume (Vas)2ft³
Mechanical Compliance of Suspension (Cms)0.88mm/N
BL Product (BL)9.05T·m
Diaphragm Mass Inc. Airload (Mms)35.8g
Maximum Linear Excursion (Xmax)7mm
Surface Area of Cone (Sd)213.8cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.78"
Baffle Cutout Diameter7.24"
Depth3.5"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.45ft³
Sealed F368Hz
Vented Volume1.4ft³
Vented F334Hz

Specifications

Q&A

Reviews

Manuals & Resources

  • Dayton Audio RS225-8 Graphs/FRD/ZMA Data File
  • Dayton Audio RS225-8 Specifications
  • Dayton Audio Manufacturer Warranty
