Dayton Audio AMTPRO-4 Air Motion Transformer Tweeter 4 Ohm

Dayton Audio
Part #275-094

Dayton Audio AMTPRO-4 Air Motion Transformer Tweeter 4 Ohm

Dayton Audio
Part #275-094
Model: AMTPRO-4
The Dayton Audio AMTPRO-4 Air Motion Transformer is designed for professional audio and demanding high-fidelity applications in which high SPL demands combine with the need for detailed reproduction and musical finesse.
Key Features
  • Folded Kapton ribbon diaphragm delivers clean, detailed, and highly dynamic output
  • Open back design permits dipole or chamber loading
  • Pro-level output and ruggedness for PA boxes, studio monitors, or high-efficiency home playback
Your Price: $99.98
+ FREE SHIPPING
MSRP: $214.99
Save $115.01 (53%)
Bulk Pricing
Order in the next 5 hr 41 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio AMTPRO-4 Air Motion Transformer Tweeter 4 Ohm

Dayton Audio's AMTPRO-4 model features an extremely large AMT diaphragm with an open-back design and powerful neodymium magnetic assembly. This combination produces high output and low distortion over a broad frequency range, while handling large amounts of amplifier power.

Perfect for use in PA loudspeakers, large-format studio monitors, custom cinema speakers, or extreme performance hi-fi loudspeakers, the AMTPRO-4 can easily be chamber-loaded or open-baffle loaded as required by a particular dipole application. Thanks to its ability to be crossed over as low as 800 Hz, the AMTPRO-4 driver is a uniquely effective solution for midrange reproduction as well as treble, and can even be used as a wide-bandwidth “mid-tweeter” driver.

Dayton Audio AMT (Air Motion Transformer) tweeters borrow technology from the original Heil Air Motion Transformer to provide ultra-clean, detailed, and dynamic treble output. The pleated ribbon diaphragm of an AMT provides a large acoustic radiating area condensed into a compact chassis, for extremely high SPL output, wide bandwidth, and improved power handling.

Product Details

BrandDayton Audio
ModelAMTPRO-4
Part Number275-094
UPC848791000645
Unit of MeasureEach
Weight2.65

Product Specifications

Cutout Diameter2.83
Tweeter TypeAMT Air Motion Transformer
Power Handling (RMS)50 Watts
Impedance4Ω
Frequency Response800 to 18,000Hz
Sensitivity94dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)800Hz
DC Resistance (Re)3.96Ω
Voice Coil Inductance (Le)0.06mH
Total Q (Qts)4.12

Mounting Information

Overall Outside Diameter7.87" x 3.94"
Depth1.42"
