  • DS18 PRO-NEO6SLIM 6-1/2" Professional Neodymium Midrange Speaker 4 Ohm

CLEARANCE DS18 PRO-NEO6SLIM 6-1/2" Professional Neodymium Midrange Speaker 4 Ohm

3 Questions, 3 Answers or
DS18
Part #294-8056

CLEARANCE DS18 PRO-NEO6SLIM 6-1/2" Professional Neodymium Midrange Speaker 4 Ohm

DS18
Part #294-8056
Model: PRO-NEO6SLIM
3 Questions, 3 Answers or
The PRO-NEO6SLIM 6-1/2" professional neodymium midrange driver from DS18 can produce powerful midrange response while requiring minimal space. The non-pressed paper cone has excellent damping properties to minimize unwanted resonances for natural and lifelike vocals. A sleek red aluminum bullet shaped dust cap improves off-axis response while improving power handling. With a powerful neodymium motor, the light weight PRO-NEO6SLIM can be installed into locations with less than 2" of depth.
Key Features
  • Advanced neodymium motor system minimizes size and weight without sacrificing output
  • Damped paper cone for natural sound and smooth midrange response
  • Handles 200 watts RMS with 96 dB efficiency to deliver incredibly high SPL
  • Red aluminum bullet dust cap looks great while improving power handling
  • 1-7/8" mounting depth allows installation where space is at a minimum
CLEARANCE $127.95
+ FREE SHIPPING
Bulk Pricing
Order in the next 19 hr 25 min to ship today. Details

1In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

DS18 PRO-NEO6SLIM 6-1/2" Professional Neodymium Midrange Speaker 4 Ohm

If you have minimal space but need high SPL midrange response, DS18's PRO-NEO6SLIM 6-1/2" professional neodymium midrange driver in an excellent solution. The naturally damped paper cone delivers natural midrange response even when driven to high output levels. An eye-catching red aluminum bullet shaped dust cap helps to improve off-axis response while wicking heat away from the voice coil for improved power handling. A compact but powerful neodymium magnet allows this driver to only require 1-7/8" of mounting depth for installation almost anywhere. Furthermore, the motor assembly is vented out of the sides making it possible to install the PRO-NEO6SLIM in locations that have zero clearance behind the driver without sacrificing performance. Capable of handling up to 200 watts RMS and with 96 dB efficiency, the PRO-NEO6SLIM proves that you don't always need a lot of space for high SPL designs.

Product Details

BrandDS18
ModelPRO-NEO6SLIM
Part Number294-8056
UPC663593058911
Unit of MeasureEach
Weight2.5

Product Specifications

Nominal Diameter6-1/2"
Power Handling (RMS)200 Watts
Power Handling (MAX)400 Watts
Impedance
Frequency Response136 to 11,000Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter1.5"

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.85"
Baffle Cutout Diameter5.82"
Depth1.8"
# Mounting Holes4
