Celestion FTR18-4080FD 18" Professional Cast Frame Speaker 1,000W

Celestion
Part #294-2014

Celestion FTR18-4080FD 18" Professional Cast Frame Speaker 1,000W

Celestion
Part #294-2014
Model: FTR18-4080FD
Celestion's FTR18-4080FD 18" cast frame 1,000 watt pro driver will deliver outstanding results when deployed in subwoofer enclosures of every configuration -- sealed, vented, horn-loaded, bandpass, and more.
Key Features
  • Well-vented ceramic ferrite magnetic assembly, 1,000 watts RMS power handling, and 97 dB sensitivity
  • 4" high temperature Inside/Outside voice coil efficiently dissipates heat, preventing sensitivity loss through thermal compression
  • Flexirol™ surround for greater excursion control
  • Low frequency response, down to 30 Hz, for deep sub-bass response
  • Double suspension for well-controlled cone travel at high power
  • Smart chassis design minimizes acoustic distortion
  • Specially treated weather-resistant cone guarantees long service life
Your Price: $269.00
+ FREE SHIPPING
MSRP: $403.50
Save $134.50 (33%)
Bulk Pricing
Ships next business day. Details

6In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Celestion FTR18-4080FD 18" Professional Cast Frame Speaker 1,000W

The Celestion FTR18-4080FD 18" pro woofer features a rigid, yet acoustically optimized cast aluminum frame and a specially treated and weather-resistant cone. Its 1,000 watt RMS power rating is achieved largely by the use of a  4" high temperature Inside/Outside voice coil that efficiently dissipates heat and prevents sensitivity loss through thermal compression. Extensive venting through the frame and motor structure also improves reliability. The FTR18-4080FD's exclusive Flexirol™ surround and double suspension guarantee exceptional linearity, even at the highest excursions.

Product Details

BrandCelestion
ModelFTR18-4080FD
Part Number294-2014
UPC739894546058
Unit of MeasureEach
Weight26.9

Product Specifications

Nominal Diameter18"
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Frequency Response30 to 2,500Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)25.2Hz
DC Resistance (Re)5.6Ω
Voice Coil Inductance (Le)1.5mH
Mechanical Q (Qms)4.75
Electromagnetic Q (Qes)0.3
Total Q (Qts)0.28
Compliance Equivalent Volume (Vas)14.43ft³
Mechanical Compliance of Suspension (Cms)0.23mm/N
BL Product (BL)22.81T·m
Diaphragm Mass Inc. Airload (Mms)177.8g
Maximum Linear Excursion (Xmax)6mm
Surface Area of Cone (Sd)1134.12cm²

Materials of Construction

Cone MaterialPaper / Glass Fiber
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter18.19"
Baffle Cutout Diameter16.38"
Depth8.07"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3ft³
Sealed F372.2Hz
Vented Volume6.63ft³
Vented F333.3Hz
