Beston RT004A-D Horn Loaded Ribbon Tweeter 8 Ohm

Beston
Part #277-118

Beston RT004A-D Horn Loaded Ribbon Tweeter 8 Ohm

Beston
Part #277-118
Model: RT004A-D
Beston's RT004A-D horn-loaded ribbon tweeter features a laminated aluminum diaphragm, driven by a compact and lightweight neodymium magnet.
Key Features
  • Patented ribbon design exhibits superb articulation and effortless dynamics
  • 1,000 Hz – 40,000 Hz frequency response
  • Horn loaded for 102 dB sensitivity
  • Ultra-thin laminated aluminum diaphragm
  • Neodymium magnet structure for high flux and low weight
  • Linear impedance simplifies filter design and amplifier requirements
Similar items that may interest you:
See all items in Planar / Ribbon Transducers
Your Price: $158.98
+ FREE SHIPPING
MSRP: $206.99
Save $48.01 (23%)
Bulk Pricing
Quantity:Qty: 1-3 $158.98/ea
Quantity:Qty: 4-9 $151.03/ea
Quantity:Qty: 10+$143.08/ea
Order in the next 3 hr 22 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Beston RT004A-D Horn Loaded Ribbon Tweeter 8 Ohm

A Beston RT004A-D tweeter's driven radiating surface mass is usefully low, and contributes to the transducer's superb range, efficiency, tonal neutrality, and transient response. The motor, diaphragm, and carefully controlled horn loading are skillfully integrated to create a perfect balance of sensitivity and wide, even dispersion. Great for MTM designs. A ribbon tweeter's radiating surface approaches the theoretical ideal of a zero-mass audio source. The articulation, attack, and sonic transparency are quite impressive, and the diaphragm's monolithic shape and orientation provide a broad horizontal and tightly controlled dispersion characteristic, which is ideal for many listening environments. Beston's carefully sculpted waveguide faceplate further improves the tweeter's linear emission of smooth, extended high frequencies. Achieve studio monitor-like audio precision with your next high-efficiency speaker project! A third order (18 dB/octave) or higher crossover is recommended to achieve maximum power handling. Minimum recommended crossover frequency: 1,500 Hz

Product Details

BrandBeston
ModelRT004A-D
Part Number277-118
UPC848864051260
Unit of MeasureEach
Weight2.75

Product Specifications

Cutout Diameter6.14 x 6.14
Tweeter TypeRibbon
Power Handling (RMS)60 Watts
Impedance8Ω
Frequency Response1,000 to 40,000Hz
Sensitivity102dB 2.83V/1m

Mounting Information

Overall Outside Diameter7.8 x 7.8"
Depth4"
