B&C 10NW76 10" Neodymium Subwoofer 8 Ohm

B&C Speakers
Part #294-6050

B&C 10NW76 10" Neodymium Subwoofer 8 Ohm

B&C Speakers
Part #294-6050
Model: 10NW76
The B&C Speakers 10NW76 10" speaker is the perfect woofer for pro audio applications, it is lightweight, powerful, and most of all, versatile.
Key Features
  • Stunning hi-fi clarity and detail, even at explosive pro concert levels
  • Neodymium magnet is light but powerful
  • Ventilated voice coil gap reduces power compression
  • Aluminum shorting ring help control the voice coil for lower distortion
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $301.06
+ FREE SHIPPING
MSRP: $501.77
Save $200.71 (40%)
Bulk Pricing
Ships next business day. Details

10In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C 10NW76 10" Neodymium Subwoofer 8 Ohm

The B&C Speakers 10NW76 10" speaker is lightweight, powerful, and versatile. Its midrange efficiency and clarity make it a great choice for professional midbass or midrange applications, but its bass capabilities mark it as a dynamic, punchy woofer in compact 2-way speaker systems. The 10NW76 will deliver great performance in sealed, bass reflex, or horn loaded enclosures.

Product Details

BrandB&C Speakers
Model10NW76
Part Number294-6050
UPC848864058207
Unit of MeasureEach
Weight9.85

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.69
Power Handling (RMS)400 Watts
Power Handling (MAX)800 Watts
Impedance8Ω
Frequency Response65 to 3,500Hz
Sensitivity96.3dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)67Hz
DC Resistance (Re)5.5Ω
Voice Coil Inductance (Le)0.38mH
Mechanical Q (Qms)7.8
Electromagnetic Q (Qes)0.27
Total Q (Qts)0.26
Compliance Equivalent Volume (Vas)0.62ft³
BL Product (BL)20T·m
Diaphragm Mass Inc. Airload (Mms)47g
Maximum Linear Excursion (Xmax)6.8mm
Surface Area of Cone (Sd)320cm²

Materials of Construction

Voice Coil FormerFiberglass
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter10.28"
Baffle Cutout Diameter9.17"
Depth4.69"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Vented Volume0.63ft³
Vented F370.9Hz
