Yorkville C160W Coliseum Mini Series 4" Ceiling Speaker 70V - White

Yorkville
Part #245-956

Yorkville C160W Coliseum Mini Series 4" Ceiling Speaker 70V - White

Yorkville
Part #245-956
Model: C160W
Ideal for any paging or background music system, the Yorkville C160W 10 watt, 4" diameter flush mount-ceiling speaker designed specifically for quick and simple installation in office and retail environments. . The C160W can be easily installed and driven by any 70 volt amplification system.
Key Features
  • Full range of sub-compact installation specific models ranging from 5 watt wall speakers to 100 watt professional quality cabinets
  • Attractive and discrete white paintable finish
  • ABS pot light speaker cabinet with built in 70V transformer and taps and solder lug inputs
Your Price: $25.00
MSRP: $36.00
Save $11.00 (31%)
Bulk Pricing
Order in the next 5 hr 30 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Yorkville C160W Coliseum Mini Series 4" Ceiling Speaker 70V - White

Ideal for any paging or background music system, the C160W is a 10 watt, 4" diameter flush mount-ceiling speaker designed specifically for quick and simple installation in office and retail environments. The C160W has built in 70 volt transformer and taps, and can operate at 2.5, 5, or 10 watts. It also features an efficiency of 92dB (1 W/m) and a frequency response of 150 - 20,000 Hz. Rugged ABS plastic construction in a ‘pot light’ format with an all metal grille make the C160W ideal for any drywall or tile drop ceiling mount application. The C160W can be easily installed and driven by any 70 volt amplification system, including the Coliseum CA1, CA1T or CA12.

Specifications: • Speaker type: Full range 'pot light' • Power handling: 10 W • Transformer taps: 2.5, 5, 10W / 8 ohm passive bypass • Sensitivity: 92 dB @ 1W/1m • Frequency response: 150 - 20,000 Hz • Woofer size: 4" • Inputs: Solder lugs • Cabinet construction: Injection Molded ABS Plastic • Hardware: Ceiling mount clips • Color: White • Dimensions: 5.6 " D x 5.6" W x 4.8" H • Weight: 3 lbs.

Constant Voltage (70-Volt) Audio Systems

Audio distribution systems, especially those commonly used in department stores, warehouses, restaurants, etc., require that many loudspeakers be driven from a single audio amplifier over long runs of speaker wire.  The "constant voltage" or "high impedance distribution" audio systems can be complex to understand at first, however, provides many advantages. Learn how to design your own 70-volt or 25-volt loudspeaker system.

Learn More

Product Details

BrandYorkville
ModelC160W
Part Number245-956
UPC840402011170
Unit of MeasureEach
Weight2.15
