Wavecor TW030WA13 30mm Textile Dome Neodymium Tweeter with Heat Sink and Rear Chamber 4 Ohm

Wavecor
Part #298-1124

Wavecor TW030WA13 30mm Textile Dome Neodymium Tweeter with Heat Sink and Rear Chamber 4 Ohm

Wavecor
Part #298-1124
Model: TW030WA13
The Wavecor TW030WA13 is a true high-end tweeter designed for the most demanding applications featuring an array of performance improving details that participate in obtaining low resonance frequency, low distortion and very high frequency extension.
Key Features
  • Vented through to a damped rear chamber for low resonance frequency and low distortion
  • 30 mm voice coil design with high power handling, and low resonance frequency
  • Precision-coated textile diaphragm for improved consistency and high-frequency extension
  • Copper clad center pole yielding very low voice coil inductance for reduced distortion and increased high frequency output
  • Flexible lead wires for higher power handling and larger excursion
  • Gold plated terminals to prevent oxidation and ensure long-term reliable connection
  • Rear heat sink for increased long term power handling
Your Price: $118.00
+ FREE SHIPPING
Bulk Pricing
Order in the next 5 hr 1 min to ship today. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Wavecor TW030WA13 30mm Textile Dome Neodymium Tweeter with Heat Sink and Rear Chamber 4 Ohm

The Wavecor TW030WA13 is a true high-end tweeter designed for the most demanding applications featuring an array of performance improving details that participate in obtaining low resonance frequency, low distortion and very high frequency extension.

The low resonant frequency of this tweeter makes the TW030WA13 a natural candidate for high-end 2-way speaker systems.

Product Details

BrandWavecor
ModelTW030WA13
Part Number298-1124
UPC848864054636
Unit of MeasureEach
Weight0.29

Product Specifications

Cone / Dome Diameter1.125"
Cutout Diameter2.28
Tweeter TypeSoft Dome
Power Handling (RMS)35 Watts
Impedance
Frequency Response2,000 to 30,000Hz
Sensitivity93.5dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)690Hz
DC Resistance (Re)3.5Ω
Voice Coil Inductance (Le)33mH
Mechanical Q (Qms)2.45
Electromagnetic Q (Qes)1.72
Total Q (Qts)1.01

Mounting Information

Overall Outside Diameter2.99"
Depth1.5"
