  • WONDOM AA-AB32178 2x50W 4 Ohm Class D Audio Amplifier Board - TPA3116

CLEARANCE WONDOM AA-AB32178 2x50W 4 Ohm Class D Audio Amplifier Board - TPA3116

WONDOM
Part #320-3342

CLEARANCE WONDOM AA-AB32178 2x50W 4 Ohm Class D Audio Amplifier Board - TPA3116

WONDOM
Part #320-3342
Model: AA-AB32178
The TPA3116 Class D amplifiers provide high-performance, thermally efficient amplifier solutions. This board delivers 100 watts of power in a small package.
Key Features
  • Mute and standby function eliminates popping noise
  • Convenient 8 to 26 VDC input voltage
  • Thermal and output current protection
  • Small 3.6" x 2.7" foot print for small projects
Similar items that may interest you:
See all items in Audio Amplifier Boards & Modules
CLEARANCE $31.98
Bulk Pricing
Quantity:Qty: 1-3 $31.98/ea
Quantity:Qty: 4-9 $30.39/ea
Quantity:Qty: 10+$28.78/ea
Ships next business day. Details

250In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

WONDOM AA-AB32178 2x50W 4 Ohm Class D Audio Amplifier Board - TPA3116

Don't let the size fool you, the TPA3116 amp board delivers 2 x 50W into 4? loads. This device operates from 8V to 26V and provides a high PSRR, eliminating the need for a regulated power supply. The TPA3116 has the ability to be used as a small car amplifier, because it offers up to 90% efficiency at 12 VDC.

Comprehensive click-and-pop reduction circuitry minimizes noise coming into and out of shutdown or mute. Work this amp board into your next small portable speaker project and enjoy the sound without the annoying pop sound when you turn it off.

Specifications:
• Power output (w/ 21 VDC power supply): 50W RMS x 2 (4 ohms, THD 10%), 25W RMS x 2 (4 ohms, THD 0.1%)
• Frequency response: 20 to 22,000 Hz (±3 dB)
• Minimum impedance: 4 ohms
• Recommended power supply: 8 to 26 VDC @ 4A
• Power input jack: 2.5 x 5.5 mm, center-positive
• Dimensions: 3.6" L x 2.7" W x 0.9" H

Product Details

BrandWONDOM
ModelAA-AB32178
Part Number320-3342
UPC843577100380
Unit of MeasureEach
Weight0.3

Product Specifications

Board Type2 Channel Stereo Amp
Power (RMS/Channel 8 ohms)26 - 50 Watts
