Timpano Audio TPT-MD12 PRO 12" Midrange Speaker 8 Ohm

Timpano Audio
Part #294-3332

Timpano Audio TPT-MD12 PRO 12" Midrange Speaker 8 Ohm

Timpano Audio
Part #294-3332
Model: TPT-MD12 PRO
Timpano Audio's TPT-MD12 PRO 12" midbass speaker is a great choice for adding some high output midbass to professional and automotive sound systems. With a large vented ferrite magnet and 3" voice coil, this driver is ideal for use in high output applications. Capable of handling a massive 400 watts RMS and with a sensitivity of 101 dB, the TPT-MD12 PRO is designed to deliver continuous high SPL midbass output.
Key Features
  • Broad 55-3,000 Hz frequency range for ultimate flexibility
  • Massive 101 dB sensitivity for maximum output with minimal power
  • Large vented ferrite motor for increased output and power handling
  • Strong and lightweight cast aluminum frame
  • 0.38 total Q for sealed or vented enclosures
Your Price: $119.95
+ FREE SHIPPING
MSRP: $149.94
Save $29.99 (20%)
Bulk Pricing
Order in the next 5 hr 31 min to ship today. Details

Only 4 In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Timpano Audio TPT-MD12 PRO 12" Midrange Speaker 8 Ohm

The TPT-MD12 PRO 12" midbass speaker from Timpano Audio is built like a professional midbass, but has been designed for use in the mobile audio market. With a naturally damped paper cone and dual roll cloth surround, this driver keeps resonances under control for natural response. The 3" voice coil and powerful vented magnet are designed to allow high sensitivity and increased power handling. Due to a Qts of 0.38, this will work perfectly in vented or sealed enclosures.

Product Details

BrandTimpano Audio
ModelTPT-MD12 PRO
Part Number294-3332
UPC611056239001
Unit of MeasureEach
Weight17.3

Product Specifications

Nominal Diameter12"
Power Handling (RMS)400 Watts
Power Handling (MAX)800 Watts
Impedance8Ω
Frequency Response55 to 3,000Hz
Sensitivity101dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)51.7Hz
DC Resistance (Re)5.5Ω
Mechanical Q (Qms)10.7
Electromagnetic Q (Qes)0.39
Total Q (Qts)0.38
Compliance Equivalent Volume (Vas)3.4ft³
Mechanical Compliance of Suspension (Cms)0.21mm/N
BL Product (BL)14.3T·m
Diaphragm Mass Inc. Airload (Mms)45.2g
Surface Area of Cone (Sd)573cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1ft³
Sealed F3108.1Hz
Vented Volume2.25ft³
Vented F355Hz
