  • Timpano Audio TPT-1000.4 2 Ohm 1,000 Watt 4 Channel Car Audio Amplifier

Timpano Audio TPT-1000.4 2 Ohm 1,000 Watt 4 Channel Car Audio Amplifier

2 Questions, 3 Answers or
Timpano Audio
Part #294-4134

Timpano Audio TPT-1000.4 2 Ohm 1,000 Watt 4 Channel Car Audio Amplifier

Timpano Audio
Part #294-4134
Model: TPT-1000.4 2 Ohms
2 Questions, 3 Answers or
The Timpano TPT-1000.4 2 Ohms is a very efficient Class D full range 4-channel car audio amplifier that has an extremely compact footprint for its power output. Loaded with features, the TPT-1000.4 2 Ohms provides an unsurpassed efficiency rate of 80-90% in a compact Class D full range amplifier.
Key Features
  • Delivers 4 x 140 watts RMS and bridgeable to 2 x 450 watts (4 ohms) for high output capability
  • Brazilian class-D technology for incredible efficiency and compact footprint
  • Built-in crossovers for the front and rear channels makes it simple to integrate into most systems
  • Smart electronic 2-way protection circuit protects the amp if it gets too hot or if speakers fail
Your Price: $119.95
+ FREE SHIPPING
MSRP: $162.44
Save $42.49 (26%)
Bulk Pricing
Order in the next 19 hr 51 min to ship today. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Timpano Audio TPT-1000.4 2 Ohm 1,000 Watt 4 Channel Car Audio Amplifier

For mobile audio installation that are short on space, the TPT-1000.4 2 Ohms 4-channel car audio amplifier from Timpano Audio is the perfect solution. This 4 x 225 watt (at 2 ohms) amplifier will produce a surprising amount of output capability from an compact 8" x 8" x 2.6" package. Capable of handling a 2 ohm load or bridgeable to 2-channels, the TPT-1000.4 2 Ohms actually has the power and flexibility of much larger amplifiers. For simple tuning and level matching, this compact powerhouse features front and rear switchable high/low pass crossovers along with adjustable gains. Finally, a smart electronic 2-way protection circuit protects the amp if it gets too hot or if speakers fail causing a short. All of this makes the TPT-1000.4 2 Ohms ideal for powering motorcycle and ATV sound systems, or any mobile audio system with very little available space.

Specifications:
• Number of Channels: 4
• RMS Power at 2 Ohms 12.6V: 4 x 225W
• RMS Power at 4 Ohms 12.6V: 4 x 140W
• Bridged RMS Power at 4 Ohms 12.6V: 2 x 450W
• Supply Voltage: 11 ~ 16V
• Frequency Response: 20 Hz - 26 kHz
• Crossover Low Pass: fixed at 90 Hz
• Crossover High Pass: Fixed at 90 Hz
• Signal to Noise: >90 dB
• Harmonic Distortion: <0.9 % THD
• Input sensitivity: 0.2 V
• Input Impedance: 14K Ohms
• Impedance Output: 2 Ohms
• Consumption with Signal Musical: 4A ~ 50A
• Dimensions (L x W x H): 8.11" x 8.11" x 2.6"
• Weight: 3.75 lbs

Product Details

BrandTimpano Audio
ModelTPT-1000.4 2 Ohms
Part Number294-4134
UPC611056239322
Unit of MeasureEach
Weight4

Product Specifications

Input TypeRCA Line Level
Output Channels4
RMS Power Output (4 Ohms)140
Special Features2 ohm Stable-Bridgeable
