Tang Band T1-1942SB Speaker Module 2-5/16" x 2-5/16"

Tang Band
Part #264-934

Tang Band T1-1942SB Speaker Module 2-5/16" x 2-5/16"

Tang Band
Part #264-934
Model: T1-1942SB
Tang Band's T1-1942SB features a passive radiator-assisted 46 mm driver that plays from 75 to 20,000 Hz in a tiny 2.32" package. Design modern speakers never before thought possible.
Key Features
  • 46 mm polypropylene-composite inverted dome driver
  • Rear-mounted passive radiator extends response to 75 Hz
  • Tiny 2.32" self-contained design
  • Just add an amplifier for high-quality, full-range sound!
Your Price: $41.98
MSRP: $62.99
Save $21.01 (33%)
Bulk Pricing
Quantity:Qty: 1-3 $41.98/ea
Quantity:Qty: 4-9 $39.88/ea
Quantity:Qty: 10+$37.78/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Tang Band T1-1942SB Speaker Module 2-5/16" x 2-5/16"

Tang Band's line of patented speaker modules are designed for modern audio applications such as sound bars, desktop multimedia speakers, flat panel TV speakers, and portable audio systems. Don't let Tang Band's diminutive driver modules fool you; each is built with a passive radiator that extends midbass frequency response, allowing these to mate to a subwoofer system quite easily.

The T1-1942SB speaker module is built around a passive radiator assisted, polypropylene composite 46 mm inverted dome driver. This allows for a very full frequency response from a single, small driver. Advantages of this type of speaker design include the elimination of crossover components in the critical midrange, superb off-axis response due to the use of a small driver (without hot spots), and perfect time-alignment.

Note: Tang Band recommends the use of a 2nd order (-12 dB/octave) 80 Hz high pass filter for the best possible sound. Higher power handling and output is possible by deploying multiple modules together.

Product Details

BrandTang Band
ModelT1-1942SB
Part Number264-934
UPC848864015118
Unit of MeasureEach
Weight0.35

Product Specifications

Nominal Diameter2"
Bolt Circle Diameter2.6
Power Handling (RMS)4 Watts
Power Handling (MAX)8 Watts
Impedance4Ω
Frequency Response75 to 20,000Hz
Sensitivity82dB 2.83V/1m
Voice Coil Diameter1.1"

Thiele-Small Parameters

Resonant Frequency (Fs)75Hz

Materials of Construction

Cone MaterialPoly Composite
Surround MaterialRubber
Basket / Frame MaterialPolymer
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter2.32" x 2.32"
Baffle Cutout Diameter2.20"
Depth1.72"
# Mounting Holes4
