  • Lavoce WAN124.01 12" Neodymium Woofer

CLEARANCE Lavoce WAN124.01 12" Neodymium Woofer

Lavoce
Part #293-814

CLEARANCE Lavoce WAN124.01 12" Neodymium Woofer

Lavoce
Part #293-814
Model: WAN124.01

The LaVoce WAN124.01 is a powerful 12" woofer that features an impressive aluminum basket which provides exceptional cooling. A 4" voice coil and above average excursion make this a great choice for high powered bass applications.

Key Features
  • FEM optimized neo motor and suspensions
  • Optimized cooling system for reliable performance
  • Resonance-free, heavy-duty aluminum basket demonstrates excellent build quality
CLEARANCE $319.00
+ FREE SHIPPING
MSRP: $476.12
Save $157.12 (33%)
Bulk Pricing
Order in the next 5 hr 11 min to ship today. Details

1In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Lavoce WAN124.01 12" Neodymium Woofer

The LaVoce WAN124.01 is a powerful 12" woofer that features an impressive aluminum basket which provides exceptional cooling. A 4" voice coil and above average excursion make this a great choice for high powered bass applications. The gasket on this driver allows it to be rear mounted easily, providing additional installation flexibility. To add to the versatility of this driver, the cone has been treated to be waterproof, making it ideal for outdoor cabinets. A powerful neo motor keeps weight down without sacrificing power handling and output capability.

Product Details

BrandLavoce
ModelWAN124.01
Part Number293-814
UPC848864072784
Unit of MeasureEach
Weight19.5

Product Specifications

Nominal Diameter12"
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Frequency Response40 to 2,000Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)40Hz
DC Resistance (Re)5Ω
Voice Coil Inductance (Le)1.7mH
Mechanical Q (Qms)4
Electromagnetic Q (Qes)0.22
Total Q (Qts)0.21
Compliance Equivalent Volume (Vas)1.8ft³
Mechanical Compliance of Suspension (Cms)0.12mm/N
BL Product (BL)26.8T·m
Maximum Linear Excursion (Xmax)8.5mm
Surface Area of Cone (Sd)540cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter12.40"
Baffle Cutout Diameter11.28"
Depth5.54"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Vented Volume1.625ft³
Vented F347Hz
