Product Details | |
|---|---|
| Brand | Factory Buyouts |
| Model | JAL803 |
| Part Number | 299-4202 |
| UPC | 848864073484 |
| Unit of Measure | Each |
| Weight | 1 |
Product Specifications | |
|---|---|
| Nominal Diameter | 8" |
| Bolt Circle Diameter | 7 |
| Power Handling (RMS) | 12 Watts |
| Power Handling (MAX) | 24 Watts |
| Impedance | 4Ω |
| Frequency Response | 90 to 6,000Hz |
| Sensitivity | 85.77dB 2.83V/1m |
| Voice Coil Diameter | 0.75" |
Thiele-Small Parameters | |
|---|---|
| Resonant Frequency (Fs) | 91.28Hz |
| DC Resistance (Re) | 3.483Ω |
| Voice Coil Inductance (Le) | 0.1507mH |
| Mechanical Q (Qms) | 13.14 |
| Electromagnetic Q (Qes) | 7.914 |
| Total Q (Qts) | 4.939 |
| Compliance Equivalent Volume (Vas) | 0.8972ft³ |
| Diaphragm Mass Inc. Airload (Mms) | 8.864g |
| Maximum Linear Excursion (Xmax) | 1.5mm |
| Surface Area of Cone (Sd) | 232.4cm² |
Materials of Construction | |
|---|---|
| Cone Material | Paper |
| Surround Material | Paper |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Paper |
| Basket / Frame Material | Steel |
| Magnet Material | Ferrite |
Mounting Information | |
|---|---|
| Overall Outside Diameter | 8.125" |
| Baffle Cutout Diameter | 7.25" |
| Depth | 2.625" |
| # Mounting Holes | 4 |
