Overview
The FiiO D3 DAC Coaxial/Optical to R/L Audio Converter is a high-quality option for taking devices that have no analog outputs, such as many modern televisions, and pairing them with stereo equipment that that lacks digital inputs. It also works as a modern and cost-effective upgrade for aging CD players with digital outputs.
Specifications:
• Input: S/PDIF coaxial or optical, up to 192 kHz/24-bit
• Power supply: 5 VDC via mini-USB connector, power supply not included
• Output power: 1.6V
• Frequency response: 20-20,000 Hz
• Signal to noise ratio: ≥95 dB
• Crosstalk: 85 dB
• Total harmonic distortion: <0.008%
• Dimensions (L x W x H): 2.46" x 1.96" x 0.84"
Note: The digital input signal format for this DAC convertor is PCM. The ability to use this DAC device with a television to convert the digital audio output to analog audio is specific to the television. Check your television user manual to see if the S/PDIF output can be changed from Dolby Digital to PCM.
