  • Dayton Audio RS28F-4 1-1/8" Silk Dome Tweeter

CLEARANCE Dayton Audio RS28F-4 1-1/8" Silk Dome Tweeter

Dayton Audio
Part #275-140

CLEARANCE Dayton Audio RS28F-4 1-1/8" Silk Dome Tweeter

Dayton Audio
Part #275-140
Model: RS28F-4
Dayton Audio's Reference Series tweeters are designed to complement the RS woofers. The RS28F-4 incorporates an optimized silk diaphragm that combines low mass, superb damping, and a carefully calculated dome profile.
Key Features
  • 1-1/8" silk dome provides articulate yet non-fatiguing HF reproduction
  • Tuned rear chamber and excellent power handling support low, low crossover points
  • High flux density/low-distortion motor system with copper shorting rings
  • Cast aluminum faceplate with protective mesh grill
  • Perfect for home theater or audiophile speakers
Similar items that may interest you:
See all items in Tweeters

Overview

Dayton Audio RS28F-4 1-1/8" Silk Dome Tweeter

Dayton Audio's Reference Series tweeters are designed to complement the RS woofers. The RS28F-4 incorporates an optimized silk diaphragm that combines low mass, superb damping, and a carefully calculated dome profile. A tuned rear chamber, supported by a rugged diaphragm assembly, enables crossover possibilities in ranges as low as 1,000~1,100 Hz (with the appropriate filter). This unique 1-1/8" silk dome and a state-of-the-art Ferrofluid cooled motor system employs copper shorting rings to ensure that high frequency content is reproduced as transparently as possible, assuring studio-quality performance. RS28F-4 tweeters not only match the look and features of the RS woofers but also the clean, detailed, and uncolored sound that characterizes the entire series.

Product Details

BrandDayton Audio
ModelRS28F-4
Part Number275-140
UPC844632080371
Unit of MeasureEach
Weight1.8

Product Specifications

Cone / Dome Diameter1.125"
Cutout Diameter2.88
Tweeter TypeSoft Dome
Power Handling (RMS)100 Watts
Impedance4Ω
Frequency Response1,200 to 20,000Hz
Sensitivity90.6dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)545Hz
DC Resistance (Re)2.8Ω
Voice Coil Inductance (Le)0.34mH
Mechanical Q (Qms)2.3
Electromagnetic Q (Qes)1
Total Q (Qts)0.7

Mounting Information

Overall Outside Diameter4.13"
Depth1.81"
