DS18 PRO-X8.4M 8" Professional Midrange Speaker 4 Ohm

3 Questions, 5 Answers or
DS18
Part #294-8038

DS18 PRO-X8.4M 8" Professional Midrange Speaker 4 Ohm

DS18
Part #294-8038
Model: PRO-X8.4M
3 Questions, 5 Answers or
The PRO-X8.4M 8" pro midrange speaker from DS18 is designed to bring concert level output capabilities to the car audio market. A low mass paper cone and powerful motor gives the PRO-X8.4M great efficiency and the ability to hit extreme sound pressure levels. This is a great choice for filling in the midbass and midrange frequencies in any high SPL sound systems.
Key Features
  • Paper cone with excellent damping properties produces realistic and detailed midrange response
  • Low mass and powerful motor to deliver high efficiency and dynamic output
  • Huge ferrite magnet ensures low power compression even after long listening sessions
  • 1-1/2" high temperature voice coil handles 275 watts RMS for extreme SPL
  • Just over 3" mounting depth allows installation into tight locations
Your Price: $53.95
Bulk Pricing
Ships next business day. Details

Only 4 In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

DS18 PRO-X8.4M 8" Professional Midrange Speaker 4 Ohm

Built for clean and realistic midrange at maximum SPL, DS18's PRO-X8.4M 8" pro midrange driver can deliver concert level output with audiophile quality sound. The lightweight non-pressed paper cone and copper coated aluminum voice coil wire keeps moving mass low for dynamic response. That low mass combined with a powerful motor ensure high efficiency and excellent control. With a massive ferrite magnet and 1.5" high temperature voice coil former, the PRO-X8.4M can take up to 275 watts RMS continuously with minimal power compression. This driver will be an excellent addition to high output sound systems built to blow away the competition.

During the focused R&D period of perfecting the PRO-EXL line, DS18 identified the opportunity to spawn off another line since there was a division amongst competition and concert audiophiles. Therefore, DS18 created the PRO audio line, which features a wide variety of midranges that produce concert-like sounds that will knock the wind out of you!

Product Details

BrandDS18
ModelPRO-X8.4M
Part Number294-8038
UPC810005183000
Unit of MeasureEach
Weight5.95

Product Specifications

Nominal Diameter8"
Power Handling (RMS)275 Watts
Power Handling (MAX)550 Watts
Impedance
Frequency Response80 to 13,000Hz
Sensitivity98.2dB 2.83V/1m
Magnet Weight30oz.

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Baffle Cutout Diameter7.16"
Depth3.11"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.63ft³
Sealed F3129Hz
Vented Volume0.88ft³
Vented F388.8Hz
