  • DS18 PRO-TWN1 1" Professional Titanium Neodymium Slim Bullet Tweeter 4 Ohm

DS18 PRO-TWN1 1" Professional Titanium Neodymium Slim Bullet Tweeter 4 Ohm

DS18
Part #294-8108

DS18 PRO-TWN1 1" Professional Titanium Neodymium Slim Bullet Tweeter 4 Ohm

DS18
Part #294-8108
Model: PRO-TWN1
Small, sleek, and loud are the three words that perfectly describe the Pro-TWN1 1" titanium bullet tweeter from DS18. This compact tweeter is made for loud clear high frequencies and packs an amazing punch utilizing the Neodymium magnet for minimal size and maximum sensitivity. A low mass 1" titanium diaphragm allows incredible detail with a sensitivity of 104db. The aluminum frame of the tweeter is highly durable and lightweight. Easily mountable in almost any location, this tweeter is what you need for screaming highs in a tight space.
Key Features
  • Handles up to 60 watts RMS with 104 dB sensitivity for incredible output capability
  • Rigid 1" titanium diaphragm produces accurate response up to 20,000 Hz
  • Powerful neodymium motor minimizes size and weight without sacrificing performance
  • Durable cast aluminum housing helps dissipate heat during long periods at high output
  • Less than 1-3/4" mounting depth for installation into compact locations
Your Price: $33.95
Bulk Pricing

Out of Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

DS18 PRO-TWN1 1" Professional Titanium Neodymium Slim Bullet Tweeter 4 Ohm

Built to provide concert level output for auto sound systems, the compact DS18 Pro-TWN1 1" titanium bullet tweeter is a great choice for high SPL systems that are short on space. With a sensitivity of 104 dB and capable of handling up to 60 watts RMS, this tweeter has the ability to produce extremely high output to easily cut through background noise. Thanks to the powerful neodymium motor, the Pro-TWN1 requires less than 1-3/4" of depth for easy installation with minimal space. The 1" titanium diaphragm will deliver incredible detail and dynamics with minimal unwanted resonances. The Pro-TWN1 is the ideal choice when you need a tweeter that doesn't take up much room.

Specifications: • Power handling: 60 watts RMS (120 watts max) • Minimum recommended crossover point: 3,000 Hz • VCdia: 1" • Impedance: 4 ohms • Frequency response: 3,000-20,000 Hz • SPL: 104 dB 1W/1m • Dimensions: 2.93" diameter x 1.87" deep • Mounting dimensions: 2.28" cutout diameter x 1.61" depth.

Product Details

BrandDS18
ModelPRO-TWN1
Part Number294-8108
UPC810005183079
Unit of MeasureEach
Weight1.15

Product Specifications

Cutout Diameter2.28
Diaphragm MaterialTitanium
Power Handling (RMS)60 Watts
Impedance
Frequency Response3,000 to 20,000Hz
Sensitivity104dB 2.83V/1m

Mounting Information

Overall Outside Diameter2.93"
Depth1.87"

Specifications

Q&A

Reviews

Manuals & Resources
