NEW Celestion FTX1025 10" Coaxial Full-Range Professional Driver

Celestion
Part #294-2510

NEW Celestion FTX1025 10" Coaxial Full-Range Professional Driver

Celestion
Part #294-2510
Model: FTX1025

The Celestion FTX1025 10" coaxial speaker's high-strength LF/HF motor, Polyimide diaphragm HF driver, and FEA-optimized design produce high output and minimal distortion.

Key Features
  • Coaxial HF driver with 1" voice coil, Polyimide diaphragm, and 100° X 100° coverage
  • High-energy ferrite magnet shared by LF and HF components
  • Woofer's edge-wound CCA 2.5" voice coil ensures good power handling
  • 2 kHz recommended crossover point
  • Use with passive or active crossover (not included)
NEW $259.00
+ FREE SHIPPING
MSRP: $388.50
Save $129.50 (33%)
Bulk Pricing

Back-Ordered

Estimated back in stock 1/31/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Celestion FTX1025 10" Coaxial Full-Range Professional Driver

Celestion's FTX1025 10" coaxial loudspeaker produces generous amount of low-distortion output despite its compact form factor. The FTX1025 offers resolution and accuracy that are suitable for professional "fill" loudspeakers, stage monitor wedges, studio monitors, or high-efficiency home audio systems. Power handling is 600 watts continuous program; combined with the driver's high efficiency, this results in very good maximum output. The FTX1025's large-format HF compression driver permits an exceptionally low crossover point of 2,000 Hz, which offers a more consistent directivity transition from LF cone to HF horn.


Product Details

BrandCelestion
ModelFTX1025
Part Number294-2510
UPC739894599658
Unit of MeasureEach
Weight11.4

Product Specifications

Nominal Diameter10"
Power Handling (RMS)300 Watts
Power Handling (MAX)600 Watts
Impedance8Ω
Frequency Response60 to 20,000Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)71.5Hz
DC Resistance (Re)5.42Ω
Voice Coil Inductance (Le)0.48mH
Mechanical Q (Qms)2.788
Electromagnetic Q (Qes)0.523
Total Q (Qts)0.44
Compliance Equivalent Volume (Vas)0.91ft³
Mechanical Compliance of Suspension (Cms)0.15mm/N
BL Product (BL)12.3T·m
Diaphragm Mass Inc. Airload (Mms)32.55g
Maximum Linear Excursion (Xmax)5mm
Surface Area of Cone (Sd)346.36cm²

Materials of Construction

Cone MaterialPaper / Kevlar
Surround MaterialCloth
Voice Coil Wire MaterialAluminum
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.24"
Baffle Cutout Diameter9.25"
Depth4.84"
# Mounting Holes4
