Adire Audio ADBR10D4RA Brahma 10" XBL DVC Subwoofer

Read 1 Review or
Adire Audio
Part #294-110

Adire Audio ADBR10D4RA Brahma 10" XBL DVC Subwoofer

Adire Audio
Part #294-110
Model: ADBR10D4RA
Read 1 Review or
The legend is back! Parts Express is pleased to announce the addition of Adire Audio, the makers of the original XBL^2 high excursion subwoofer drivers. The Brahma Mk2.5 RA subwoofers are upgrades to the original industry standard for low distortion, extreme linearity and excursion capability. If you are looking for ultra high-output, low distortion and near-endless excursion capability, look no further.
Key Features
  • Patented XBL^2 Linear Motor Technology
  • Hi Temp 3” Flat Wound Copper Voice Coil
  • Heavy Duty Lead Wires Interwoven into Spiders
  • Dual Progressive Spiders
  • Hand assembled in the U.S.A.
Your Price: $449.99
+ FREE SHIPPING
MSRP: $674.99
Save $225.00 (33%)
Bulk Pricing

Back-Ordered

Estimated back in stock 12/27/2024
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Adire Audio ADBR10D4RA Brahma 10" XBL DVC Subwoofer

Adire Audio ADBR10D2RA Brahma 10" XBL DVC Subwoofer

The ultimate solution for ultra high excursion, linearity and low distortion



The Adire Audio Brahma has always been known as a legendary driver in the audio industry since the very inception of the namesake in 2002. At that point in time, Adire Audio were at the forefront of high excursion drivers pushing the envelope to truly linear excursion levels never seen before. Fast forward to 2019 and they have gone back to the drawing board - updating the designs to surpass current industry standards while utilizing Patented XBL^2 motor technology to carry on the legendary namesake of the Adire Audio Brahma.

In 2021, upgrades were added to the popular Mark 2.5 Brahma design which include a new basket with custom tooled spider adapter for better fit and clearances, carbon fiber dust cap and a 100% Nomex spider for better long-term durability. These upgrades are on top of the completely revamped from-the-ground-up design implemented in 2018 which include utilizing a dual stack of Y35 Grade ceramic ferrite magnets and a fully finite element analysis optimized motor structure. Dubbed the Brahma Mark 2.5 Rev A, the driver has been made more compact than the original Brahma for the end user who may be concerned about mounting depth constraints, all the while improving the original legendary performance of the very first Brahma.



Unable to find a spider they were happy with, Adire developed their own proprietary dual 8” progressive roll spider profile. After more than 2 years of material testing, they settled on a 100% Nomex weave for long term durability. This technology is just one small piece of the redesign puzzle which adds up to allow Adire to keep the Brahma Mark 2.5 Rev A as sound quality oriented as possible, without sacrificing overall SPL output.

The Brahma Mark 2.5 Rev A carries on the world-class sound quality and tonal balance of the original Brahma while still being able to pump out insane SPL output. Doing all of the above in such a clean fashion can only be achieved using XBL^2 motor technology which is why Adire has not swayed from tradition.

The Brahma Mark 2.5 Rev A is rated at 1000 watts RMS power handling and features a 3” diameter copper voice coil available in Dual 2 or Dual 4 ohm that will keep you enjoying your music at all levels of excursion and output for many years to come.

The Brahma Mark 2.5 Rev A is an audio enthusiasts dream and will bring out the bottom octaves in a truly unique style!



Product Details

BrandAdire Audio
ModelADBR10D4RA
Part Number294-110
UPC753459858912
Unit of MeasureEach
Weight36.9

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter12
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance4Ω
Sensitivity82.53dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)29.05Hz
DC Resistance (Re)6.77Ω
Voice Coil Inductance (Le)3mH
Mechanical Q (Qms)6.74
Electromagnetic Q (Qes)0.42
Total Q (Qts)0.4
Compliance Equivalent Volume (Vas)0.73ft³
Mechanical Compliance of Suspension (Cms)0.13mm/N
BL Product (BL)25T·m
Diaphragm Mass Inc. Airload (Mms)215.33g
Maximum Linear Excursion (Xmax)28mm
Surface Area of Cone (Sd)334.5cm²

Materials of Construction

Cone MaterialPaper
Voice Coil Wire MaterialCopper
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter11"
Baffle Cutout Diameter9.25"
Depth7.25"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.43ft³
Sealed F358.2Hz
Vented Volume1ft³
Vented F325.9Hz
