ART Precision Phono Preamp with Turntable Cartridge Select

ART
Part #245-8669

ART Precision Phono Preamp with Turntable Cartridge Select

ART
Part #245-8669
Model: Precision Phono Preamp
The ART Precision Phono Preamp provides the ability to connect to any turntable with the option for choosing between moving coil and moving magnet cartridge types. With low-noise circuitry, the Precision Phono Preamp delivers exception sonic performance for both DJs and audiophiles alike.
Key Features
  • Connect any turntable to a wide variety of audio systems perfect for DJs and vinyl enthusiasts
  • Variable preamp gain, RCA preamp outputs, Switchable low-cut rumble filter
  • High accuracy/ low noise phono preamp External power supply for lower noise
  • Moving Coil/Moving Magnet cartridge switchable input
Your Price: $88.98
MSRP: $133.99
Save $45.01 (34%)
Bulk Pricing
Quantity:Qty: 1-5 $88.98/ea
Quantity:Qty: 6+$84.53/ea
Order in the next 5 hr 29 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

ART Precision Phono Preamp with Turntable Cartridge Select

ART's Precision Phono Preamp is perfect for those seeking to connect their turntable to PA or stereo in one quick and easy step. The standalone phono preamp interfaces both types of turntable cartridges Moving Coil (MC) and Moving Magnet (MM) to a wide variety of audio systems.

The Precision Phono Preamp’s extraordinarily low noise amplifier allows connection to MC cartridges without picking up noise or distortion that transformers can exhibit. The audio is kept pristine with a low-cut filter to remove rumble and low frequency feedback, commonly undesirable for DJ’s and home use.

Analog inputs on the ART Precision Phono Pre amp are switchable between Moving Magnet and Moving Coil. The unit changes both the gain and the cartridge loading to suit the selected cartridge. The front gain trim control with the signal present/clip LED allows the user to optimize the output for a wide range of cartridges.

Specifications:


• Connections: 2 x RCA in, 2 x RCA out
• Input impedance: 47 kohms / 100 pF (moving magnet), 100 ohms (moving coil)
• Max input level: 150 mV (1 kHz, MM mode), 15 mV (1 kHz, MC mode)
• Max output level: 2.5 VRMS / +10 dBu
• Max gain: 43 dB (moving magnet), 63 dB (moving coil)
• Frequency response: 20-20,000 Hz
• Low cut filters: 22 Hz, 2-pole
• THD: <0.001% (typical)
• EIN: 300 mV, -127 dBu
• Power requirements: 12 VDC, 150 mA, 9VAC / 500 mA
• Dimensions: 1.9" x 4.6" x 4.3"

Product Details

BrandART
ModelPrecision Phono Preamp
Part Number245-8669
UPC840402047650
Unit of MeasureEach
Weight1.7
