BUYOUT 40T-256A 1-1/2" Neodymium Paper Cone Tweeter 6 ohm

Factory Buyouts
Part #299-4242
Model: 40T-256A

The 40T-256A 1-1/2" Neodymium Paper Cone Tweeter utilizes an oversize neodymium motor and a very light 0.4 gram paper cone for incredible output capability.

Key Features
  • Easy installation into a 1-1/2" diameter hole
  • Third "dummy" terminal makes adding a capacitor simple
  • Paper cone for smooth natural sound
BUYOUT $0.88
Bulk Pricing
Quantity:Qty: 1-19 $0.88/ea
Quantity:Qty: 20-39 $0.78/ea
Quantity:Qty: 40+$0.68/ea
Ships next business day. Details

1077In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

40T-256A 1-1/2" Neodymium Paper Cone Tweeter 6 ohm

The 40T-256A 1-1/2" Neodymium Paper Cone Tweeter utilizes an oversize neodymium motor and a very light 0.4 gram paper cone for incredible output capability. Mounts into a 1-1/2" diameter hole with two screws.

Product Details

BrandFactory Buyouts
Model40T-256A
Part Number299-4242
UPC848864073668
Unit of MeasureEach
Weight0.1

Product Specifications

Bolt Circle Diameter1.875
Power Handling (RMS)13 Watts
Power Handling (MAX)26 Watts
Impedance6Ω
Frequency Response2,000 to 20,000Hz
Sensitivity87dB 2.83V/1m
Voice Coil Diameter0.5"

Thiele-Small Parameters

Resonant Frequency (Fs)1484Hz
DC Resistance (Re)4.665Ω
Mechanical Q (Qms)2.056
Electromagnetic Q (Qes)11.59
Total Q (Qts)1.746
Diaphragm Mass Inc. Airload (Mms)0.4g
Surface Area of Cone (Sd)10.75cm²

Materials of Construction

Surround MaterialPaper
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter1.625"
Baffle Cutout Diameter1.5"
Depth1"
# Mounting Holes2
