29PB-038B 1.1" Mylar Cone Full-Range Mini Speaker 8 Ohms Case Qty 1,000

Name: 29PB-038B 1.1" Mylar Cone Full-Range Mini Speaker 8 Ohms Case Qty 1,000
Brand: Factory Buyouts
SKU: 299-4237
Price: 299.88 USD
Availability: InStock

Factory Buyout

Part #299-4237

29PB-038B 1.1" Mylar Cone Full-Range Mini Speaker 8 Ohms Case Qty 1,000

Factory Buyout

Part #299-4237

Model: 29PB-038B

The 29PB-038B 1.1" Mylar cone full-range mini speaker's compact size and lightweight diaphragm makes it a perfect replacement driver for small electronic devices, toys, and headphones.

Key Features

Ultra-lightweight Mylar diaphragm for high efficiency
Common size driver used in many audio enabled devices

See all items in Mini Speakers

Your Price: $299.88

+ FREE SHIPPING

Bulk Pricing

Ships next business day. Details

19In Stock

Qty Quantity:

Free Shipping available on orders over $99.00 in the US. Details

60 Day No Hassle Return Policy

Overview

29PB-038B 1.1" Mylar Cone Full-Range Mini Speaker 8 Ohms Case Qty 1,000

29PB-038B 1.1" Mylar cone full-range mini speaker's compact size and lightweight diaphragm makes it a perfect replacement driver for small electronic devices, toys, and headphones. The common sized 1.1" diameter frame, press-fit design, and 8 ohm impedance makes this driver a drop in replacement for many different audio enabled toys and other devices. Case of 1,000 pcs.

Product Details
Brand	Factory Buyouts
Model	29PB-038B
Part Number	299-4237
UPC	848864075211
Weight	10

Product Specifications
Nominal Diameter	1"
Power Handling (RMS)	0.1 Watts
Power Handling (MAX)	0.2 Watts
Impedance	8Ω
Frequency Response	100 - 18,000Hz
Sensitivity	77.1dB 2.83V/1m
Voice Coil Diameter	0.25"

Thiele-Small Parameters
Resonant Frequency (Fs)	619Hz
DC Resistance (Re)	7.7Ω
Voice Coil Inductance (Le)	0.03mH
Mechanical Q (Qms)	7.37
Electromagnetic Q (Qes)	7.37
Total Q (Qts)	5
Compliance Equivalent Volume (Vas)	0.00072ft³
Mechanical Compliance of Suspension (Cms)	0.15mm/N
BL Product (BL)	0.39T·m
Diaphragm Mass Inc. Airload (Mms)	0.08g
Maximum Linear Excursion (Xmax)	0.1mm
Surface Area of Cone (Sd)	4.12cm²

Materials of Construction
Cone Material	Poly / Mylar Diaphragm
Basket / Frame Material	Polymer
Magnet Material	Ceramic Ferrite

Mounting Information
Overall Outside Diameter	1.1"
Baffle Cutout Diameter	1.1"
Depth	0.25"
