GRS 10S-8 4" Full-Range Driver 8 Ohm

GRS
Part #292-569

GRS 10S-8 4" Full-Range Driver 8 Ohm

GRS
Part #292-569
Model: 10S-8

Now you can replace blown or damaged woofers with new drivers that equal or outperform the original! GRS 10S-8 Full-range paper cone woofers are not only the perfect replacement for tired, worn-out drivers in a variety of audio gear, but they are also a great choice for new designs.

Key Features
  • Full-range frequency response from 100 to 11,000 Hz
  • Thin mount profile with a mounting depth under 1-1/2"
  • High efficiency allows excellent output capability
  • Great Replacement Speaker
Your Price: $5.59
MSRP: $14.99
Save $9.40 (63%)
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

GRS 10S-8 4" Full-Range Driver 8 Ohm

GRS 10S-8 4" Full-Range Driver 8 Ohm

A consistent and predictable driver

The GRS 10S-8 is a 4" full-range driver with low distortion characteristics and predictable performance, making this a great component for speaker designers.

Key Specs:

  • Nominal Diameter: 10
  • Power Handling (RMS): 25W
  • Power Handling (MAX): 50W
  • Impedance: 8 Ohms
  • Frequency Response: 100Hz-11kHz
  • Sensitivity: 87dB @ 2.83v/1m
  • Voice Coil Diameter: 1"

Frequency Response & Impedance Curve

the GRS 10S-8 has a wide frequency response from 100Hz to 11kHz and is highly efficient within its passband. This efficiency lends itself well to car audio uses.

Inert Poly Cone and Foam Surround

The GRS 10S-8 has a non-resonant poly cone which minimizes breakup at higher frequencies, and a treated cloth surround for high durability.

Incredibly Versatile Drivers

The GRS 10S-8 full range driver is a great contender for Car Audio installations thanks to the high-durability surround and square frame, but has a place in DIY Speaker designs thanks to it's full-range of output.

We've Got Your Back

We stand behind our products and our warranty is a demonstration of our commitment to quality and reliability.

Learn More

Learn More
Request Quote

Product Details

BrandGRS
Model10S-8
Part Number292-569
UPC848864072883
Unit of MeasureEach
Weight0.7

Product Specifications

Nominal Diameter4"
Bolt Circle Diameter4.6
Power Handling (RMS)25 Watts
Power Handling (MAX)50 Watts
Impedance8Ω
Frequency Response100-11,000Hz
Sensitivity87dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)151Hz
DC Resistance (Re)7.2Ω
Voice Coil Inductance (Le)0.21mH
Mechanical Q (Qms)7.68
Electromagnetic Q (Qes)2.1
Total Q (Qts)1.65
Compliance Equivalent Volume (Vas)1.79ft³
Mechanical Compliance of Suspension (Cms)0.46mm/N
BL Product (BL)2.8T·m
Diaphragm Mass Inc. Airload (Mms)2.4g
Maximum Linear Excursion (Xmax)1.5mm
Surface Area of Cone (Sd)52.5cm²

Materials of Construction

Cone MaterialPoly
Basket / Frame MaterialSteel

Mounting Information

Overall Outside Diameter4.1"
Baffle Cutout Diameter3.75"
Depth1.58"
# Mounting Holes4
