FaitalPRO 12RS430 12" Professional Woofer 8 Ohm

1 Question, 2 Answers or
FaitalPRO
Part #294-1332

FaitalPRO 12RS430 12" Professional Woofer 8 Ohm

FaitalPRO
Part #294-1332
Model: 12PR430
1 Question, 2 Answers or

The FaitalPRO 12RS430 12" Professional Woofer is a great choice when you need smooth response, high sensitivity and incredible bass response in average size ported or sealed enclosures.

Key Features
  • Glass fiber reinforced paper cone for smooth natural response
  • High 93 dB sensitivity for incredible output potential
  • Half roll rubber surround for clean linear excursion
  • Above average 13.57mm Xmax for impactful low-end
Your Price: $297.00
+ FREE SHIPPING
Bulk Pricing
Ships next business day. Details

2In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 12RS430 12" Professional Woofer 8 Ohm

The FaitalPRO 12RS430 12" Professional Woofer is a great choice when you need smooth response, high sensitivity and incredible bass response in average size ported or sealed enclosures.

Featuring a glass fiber reinforced paper cone, half-roll rubber surround and 400W program power handling, this woofer is ready to rock in a number of different applications. An excellent choice in a studio, small venue or even home audio environment.

Product Details

BrandFaitalPRO
Model12PR430
Part Number294-1332
UPC848864074672
Unit of MeasureEach
Weight15.9

Product Specifications

Nominal Diameter12"
Bolt Circle Diameter11.75
Power Handling (RMS)400 Watts
Power Handling (MAX)800 Watts
Impedance8Ω
Frequency Response30 to 2500Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter42.02"

Thiele-Small Parameters

Resonant Frequency (Fs)30Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)0.78mH
Mechanical Q (Qms)10
Electromagnetic Q (Qes)0.36
Total Q (Qts)0.35
Mechanical Compliance of Suspension (Cms)0.31mm/N
BL Product (BL)18T·m
Diaphragm Mass Inc. Airload (Mms)91.3g
Maximum Linear Excursion (Xmax)13.57mm
Surface Area of Cone (Sd)552cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Voice Coil Wire MaterialAluminum
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.44"
Baffle Cutout Diameter11.1"
Depth6.18"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.852ft³
Sealed F373.45Hz
Vented Volume2.205ft³
Vented F342.02Hz
