  • Electroline EDA2200 2-port Low Noise CATV Amplifier +11dB

Electroline EDA2200 2-port Low Noise CATV Amplifier +11dB

Electroline
Part #182-570

Electroline EDA2200 2-port Low Noise CATV Amplifier +11dB

Electroline
Part #182-570
Model: EDA2200
Maximize the performance of your off-air/cable distribution network with an Electroline EDA 2200 amplifier. The two-port EDA2200 is designed to boost both analog and digital signals for cable and off-air by 11.5 dB.
Key Features
  • Waterproof housing and SCTE compliant 360° F-terminals
  • Industry benchmark low-noise amplifier design
  • Rated at IEEE 6 kV 3 kA combination wave standard
  • Short-circuit protected wall adapter
Your Price: $57.98
MSRP: $73.99
Save $16.01 (22%)
Bulk Pricing
Quantity:Qty: 1-9 $57.98/ea
Quantity:Qty: 10+$56.57/ea
Order in the next 2 hr 6 min to ship today. Details

8In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Electroline EDA2200 2-port Low Noise CATV Amplifier +11dB

Maximize the performance of your off-air/cable distribution network with an Electroline EDA 2200 amplifier. The two-port EDA2200 is designed to boost both analog and digital signals for cable and off-air by 11.5 dB. Expect nothing but the highest quality signal combined with the most reliable performance. The EDA2200 features an industry benchmark for low noise at 3 dB, and the extra surge protection (XSP) has been rated at the IEEE 6 kV 3 kA combination wave standard for enhanced lightning protection. This test injects 35 times more energy than the level found in previous models, and guarantees durability that will stand the test of time. A waterproof housing and SCTE compliant 360° F-terminals ensure a nearly indestructible design, as do short-circuit protected wall adapters. Power verification is provided by a built-in confirmation LED. 5-year manufacturer's warranty.

Features and Specifications: • Number of ports: 2 • Forward gain: 11.5 dB • Return path insertion loss: 4 dB • Forward passband: 54-1000 MHz • Return passband: 5-65 MHz • Frequency response flatness: ±1 dB • Noise figure: 3 dB • RFI isolation: 100 dB minimum • Surge protection (IEEE C62.41-1991, all ports) ring wave: 6 kV, 500 A, loc. B3, combination wave: 6 kV, 3 kA, loc. B3 • Operating temperature: -40°F to 140°F (-40°C to +60°C).

Product Details

BrandElectroline
ModelEDA2200
Part Number182-570
UPC853016001024
Unit of MeasureEach
Weight1.77
