Dayton Audio DC380-8 15" Classic Woofer

Dayton Audio
Part #295-325

Dayton Audio DC380-8 15" Classic Woofer

Dayton Audio
Part #295-325
Model: DC380-8
The Dayton Audio Classic Series 15" woofer is excellent as a replacement driver or for new system design and construction. The versatile set of parameters makes it suitable for sealed or vented enclosure designs.
Key Features
  • Treated paper cone provides smooth response and low energy storage
  • Aluminum former, vented pole piece, and porous dustcap for high power handling
  • Large diameter flat spider and healthy Xmax for clean bass
  • Bring those old vintage speakers back to life
Your Price: $99.98
+ FREE SHIPPING
MSRP: $120.99
Save $21.01 (17%)
Bulk Pricing
Quantity:Qty: 1-3 $99.98/ea
Quantity:Qty: 4+$94.35/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio DC380-8 15" Classic Woofer

Dayton Audio Classic Series woofers are excellent for use as replacement speakers or for new loudspeaker system design and construction. The DC380-8 15" woofer has developed quite a reputation for having the best bang-for-the-buck performance and value available anywhere. Smooth frequency response and extended bass performance make this driver ideal for use in large format two-way and classic three-way loudspeaker designs. A Qts of 0.35 allows the DC300-8 to work well in both sealed and ported speaker enclosures.

A non-pressed treated paper cone allows for smooth frequency response, while the high temperature aluminum voice coil and vented pole piece combine to increase power handling without compression. Longevity is ensured with the use of a rubber surround, treated cloth dust cap, and an extended bump plate.

Product Details

BrandDayton Audio
ModelDC380-8
Part Number295-325
UPC844632000287
Unit of MeasureEach
Weight11.5

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.37
Power Handling (RMS)100 Watts
Power Handling (MAX)200 Watts
Impedance8Ω
Frequency Response20 to 1,500Hz
Sensitivity91.8dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)18.8Hz
DC Resistance (Re)6.4Ω
Voice Coil Inductance (Le)3.09mH
Mechanical Q (Qms)2.87
Electromagnetic Q (Qes)0.34
Total Q (Qts)0.3
Compliance Equivalent Volume (Vas)13.82ft³
Mechanical Compliance of Suspension (Cms)0.39mm/N
BL Product (BL)20.4T·m
Diaphragm Mass Inc. Airload (Mms)182.9g
Maximum Linear Excursion (Xmax)4.35mm
Surface Area of Cone (Sd)834.7cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.16"
Baffle Cutout Diameter13.74"
Depth6.38"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.25ft³
Sealed F357Hz
Vented Volume4.5ft³
Vented F331Hz
