CLEARANCE DS18 PRO-M6.2NEO 6-1/2" Professional Water Resistant Neodymium Full-Range Speaker 2 Ohm

DS18
Part #294-8052

CLEARANCE DS18 PRO-M6.2NEO 6-1/2" Professional Water Resistant Neodymium Full-Range Speaker 2 Ohm

DS18
Part #294-8052
Model: PRO-M6.2NEO
DS18's PRO-M6.2NEO 6-1/2" professional water resistant neodymium full-range driver is ideal for adding natural vocal response to motorcycle and ATV sounds systems. With 95 dB efficiency, 200 watt power handling, and 2 ohm impedance this speaker is built to produce maximum output from compact systems. With a compact but powerful neodymium motor, the PRO-M6.2NEO will deliver high SPL with minimal weight.
Key Features
  • 95dB efficiency for high output capability even with moderately powered systems
  • Smooth response up to 16,000 Hz for an easy transition to a super tweeter
  • Handles up to 200 watts RMS (with 160 Hz high pass crossover) to deliver extreme overall SPL
  • Water-resistant treatment makes this driver perfect for use in damp and exposed locations
  • Powerful neodymium motor for maximum efficiency with minimal weight
CLEARANCE $234.95
+ FREE SHIPPING
Bulk Pricing
Ships next business day. Details

2In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

DS18 PRO-M6.2NEO 6-1/2" Professional Water Resistant Neodymium Full-Range Speaker 2 Ohm

Motorcycle and ATV audio enthusiasts demand the highest quality for their high-end speakers because of the open-air environment that they love to be in. With hard riding comes with rigorous vibration and that can damage your speakers. DS18 wants motorsport lovers to feel confident in their speaker choice and not have to worry about moisture damage or vibration damage. To battle these problems, they have developed PRO-M NEO series of high efficiency speakers that are water resistant, so if you get caught in the rain, you don’t have to worry. We have also reinforced other vital parts to hold up to vibration better so you can ride hard and long in any kind of weather. The PRO-M6.2NEO helps you get the best sound possible without huge amplifiers. These neodymium variations deliver maximum efficiency and output with minimal added weight. This motor is much stronger than traditional motors giving the PRO-M6.2NEO very high sensitivity, so it can produce loud and clear sound at a lower power levels. These new neo water resistant speakers come in 2 ohm loads so you can effectively draw more power for your amp and not have to worry about bridging amps or complicated wiring. The PRO-M6.2NEO is the absolute best solution to having rugged and loud DS18 speakers in your motorcycle, ATV, or any other outdoor application that needs to withstand the elements.

Product Details

BrandDS18
ModelPRO-M6.2NEO
Part Number294-8052
UPC810005182768
Unit of MeasureEach
Weight3.4

Product Specifications

Nominal Diameter6-1/2"
Bolt Circle Diameter6.33
Power Handling (RMS)200 Watts
Power Handling (MAX)400 Watts
Impedance2Ω
Frequency Response80 to 16,000Hz
Sensitivity95dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)82Hz
Mechanical Q (Qms)7.287
Electromagnetic Q (Qes)0.386
Total Q (Qts)0.367
Compliance Equivalent Volume (Vas)0.462ft³

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.8"
Baffle Cutout Diameter5.76"
Depth2.95"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.2ft³
Sealed F3178.4Hz
Vented Volume0.5ft³
Vented F379.1Hz
